Description
Frameset
•Frame
500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle
•Fork
Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
Drivetrain
•Shifter
Shimano Ultegra R8170 Di2, 12 speed
•Front derailleur
Shimano Ultegra R8150 Di2, braze-on, down swing
•Rear derailleur
Shimano Ultegra R8150 Di2, 34T max cog
•Crank
Shimano Ultegra R8100, 52/36, 165mm length Bottom bracket
Praxis, T47 threaded, internal bearing
•Cassette
Shimano Ultegra R8101, 11-30, 12 speed
Max chainring size
1x: 54T, 2x: 56/43
Wheels
•Wheel front
Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle
•Wheel rear
Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12mm thru axle
•Skewer front
Bontrager Switch chamfered thru axle
•Skewer rear
Bontrager Switch chamfered thru axle, removable lever
•Tire
Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x25mm
Components
•Saddle
Bontrager Aeolus Elite, austenite rails, 145mm width
•Seatpost
Madone aero carbon seatpost, 0mm offset, short length
•Handlebar
Pro Vibe Evo Integrated (one-piece) Aero Bar-Stem Unit. 132mm Drop / 80mm Reach / 5° Flare. 420x115
•Handlebar tape
Ciclovation Commutolite
•Brake rotor
Shimano CL800, centerlock, 160mm front. 140 rear
